Self-Locking Design
Quick Specs
10-80:1
Ratio Range
Bronze
Wheel Material
HRC 55-62
Hardness
WG Series
High-ratio worm gear sets for high torque transmission with reliable self-locking capability.
Ratios
10:1 to 80:1
Module
0.5 - 10 mm
Worm Material
Alloy Steel
Wheel Material
Bronze
Custom Requirements?
Request QuoteKey Features
Why choose Yongyao Worm Gears
High Reduction Ratio
Single-stage ratios from 10:1 to 80:1 for compact transmission.
Self-Locking
Reliable self-locking under specific lead angle conditions.
Quiet Operation
Smooth, low-vibration transmission with continuous gear contact.
High Load Capacity
Large contact area provides excellent torque transmission.
Technical Specifications
Complete parameter overview for WG Worm Gear Series
Single-Stage Ratio
10:1, 15:1, 20:1, 25:1, 30:1, 40:1, 50:1, 60:1, 80:1
Worm Module
0.5 - 10 mm (metric)
Worm Lead
Single, Double, Triple, Quad-start
Worm Material
20CrMnTi, SCM415, SCM420, 40Cr
Wheel Material
Bronze ZCuSn10Pb1, Cast Iron
Precision Grade
DIN 3975 Grade 5-7
Heat Treatment
Induction Hardening (HRC 55-62)
Surface Treatment
Black Oxide, Zinc Plating
About Self-Locking
Understanding worm gear backdrive prevention
Self-locking capability means the worm gear will not backdrive — when the input (worm) stops rotating, the output (worm wheel) cannot rotate the worm backward. This is ideal for lifting, hoisting, and positioning applications.
Self-locking is achieved when the worm lead angle is less than the friction angle:
- Single-start worms (low lead angles): Strong self-locking capability ✓
- Multi-start worms (higher lead angles): Better efficiency but may not self-lock
Note: If self-locking is required, please specify when requesting a quote.
Industry Applications
Widely used in various industrial sectors
Worm Gear Reducers
Speed reduction units
Lifting Equipment
Hoists, jacks, lifts
Speed Regulation
Fine speed control
Packaging
Food, pharma, logistics
